High-temperature control cable is suitable for the connection line of electrical instruments and the transmission line of the automatic control system.

It is compared with ordinary plastic insulated control cables, insulation using fluorine plastic, the product has a higher level of heat resistance than ordinary control cables.

With oil resistance, waterproof, abrasion resistance, corrosive gas resistance, aging resistance, non-combustible, and other excellent performance, mainly for metallurgy, electric power, petrochemical, and other industries with special requirements for mobile temperature occasions.

The high-temperature resistant control cable is suitable for industrial and mining enterprises such as metallurgy, petroleum, chemical industry, and power plants.

It is used as a connecting line for various electrical appliances, instruments, and automatic devices under high-temperature conditions and harsh environments (such as acid, alkali, oil and water, and low-temperature conditions).

It is used for control, monitoring, and protection circuits with AC-rated voltages of 450/750V and below. This product is superior to the GB9330-88 standard.

Model and Name

KFF-poly fluoroethylene propylene insulated, poly fluoroethylene propylene sheathed control cable

KFV-poly fluoroethylene-propylene-propylene insulated PVC sheathed control cable

KVFP-polyvinyl fluoride insulated, polytetrafluoroethylene propylene sheathed shielded control cable

KFFR-poly fluoroethylene propylene insulated, poly fluoroethylene propylene sheath control flexible cable

KFVR-poly fluoroethylene propylene insulated, fluoroethylene sheathed control flexible cable.

Use Characteristics

Rated voltage: U0/U is 450/750V

Cable operating temperature: -25 ° C ~ 105 ° C

Insulation resistance between cores: (20 ° C) not less than 105 M · Ω

Conductive core DC resistance: in line with GB-3956-83

The allowable bending radius of the cable: not less than 6 times the outer diameter of the finished cable.
