Application

NYBY power cable 0,6/1 kV with Cu conductors, PVC insulated and sheathed.

Distribution of power cable for static application, mostly in-ground, but also in water, within facilities, in cable canals, and in concrete.

Used in electric power plants, transformer stations, industrial plants, metropolitan networks, and other electric plants.

Applied in conditions requiring protection against heavier mechanical damages, but where cables are not exposed to heavier tensile strain.

Standard

HRN HD 603 S1

IEC 60502-1

DIN VDE 0276 part 603

cables with 6 and more conductors:

HRN HD 627 S1

DIN VDE 027

Construction

Conductor: Cu, class 1 or 2 acc. to HRN HD 383 / IEC 60228 / DIN VDE 0295

Class 1: solid, round (RE)

Class 2: multi-wire stranded, round (RM) or sector (SM), multi-wire exceeding 50 mm2 are compacted

Insulation: PVC compound, concentrically stranded cores, color-marked acc. to HRN HD 308 S2 / VDE 0293-308, with or without a protective yellow-green conductor

Filler: spouted elastomer or elastomer compound or wrapped thermoplastic tapes

Armor: double galvanized steel tapes

Sheath: PVC compound

Sheath Colour: black

Types

Low Voltage Armoured Cable Nyby

CONTROL CABLES NYBY

NYBY ARMOURED POWER CABLE

Good Quality 0.6/1KV 4C underground Armoured power cable NYBY

Technical Data

Temperature Range

during installation: -5 °C up to +50 °C

fixed installed: -30 °C up to +70 °C

at short circuit of max. 5 s: up to 160 °C

Voltage

Nominal voltage: Uο/U = 0.6/1 kV NYBY Cable

Test voltage: 4 kV

Maximal tensile strength: 50 N/mm2

Behavior in fire: IEC 60332-1

Minimal inner bending radius

single-core: 15D

multi-core: 12D

Special version upon request

Cross-sectional area customized

Aluminum conductor required

Advantages

Excellent electric and mechanical characteristics

Best Resistance to chemical corrosion and heat-aging, environment stress, and flame-retardant

Simple in structure, Convenient to use

Reduce costs

Dimensions And Weights

number of cores x conductor cross-section	Construction	Construction of individual conductor	Insulation thickness	Sheath thickness	External diameter	Cable weight
N x mm2		N x mm	mm	mm	mm	Kg/km
Power NYBY-J, NYBY-O
2 x 4	RE	1 x 2,2	1	1,8	15,3	420
2 x 6	RE	1 x 2,7	1	1,8	16,3	493
2 x 10	RM	7 x 1,34	1	1,8	18,7	668
2 x 16	RM	7 x 1,70	1	1,8	20,9	873
3 x 4	RE	1 x 2,2	1	1,8	16	476
3 x 6	RE	1 x 2,7	1	1,8	17,1	569
3 x 10	RM	7 x 1,34	1	1,8	19,7	783
3 x 16	RM	7 x 1,70	1	1,8	22,1	1044
3 x 16+10	RM/RE	7 x 1,7/7 x 1,3	1,0 / 1,0	1,8	23,2	1163
3 x 25+16	RM/RM	7 x 2,2/7 x 1,7	1,2 / 1,0	1,8	26,2	1641
3 x 35+16	SM/RM	7 x 2,5/7 x 1,7	1,2 / 1,0	1,8	28,2	1978
3 x 50+25	SM/RM	7 x 3,/7 x 2,2	1,4 / 1,2	1,9	31,9	2606
3 x 70+35	SM/RM	13 x 2,7/7 x 2,5	1,4 / 1,2	2	35,8	3471
3 x 95+50	SM/RM	17 x 2,7/7 x 3	1,6 / 1,4	2,2	42,6	4963
4 x 1,5	RE	1 x 1,37	0,8	1,8	14,2	357
4 x 2,5	RE	1 x 1,74	0,8	1,8	15,1	424
4 x 4	RE	1 x 2,2	1	1,8	17,1	555
4 x 6	RE	1 x 2,7	1	1,8	18,3	670
4 x 10	RM	7 x 1,34	1	1,8	21,2	936
4 x 16	RM	7 x 1,70	1	1,8	23,8	1265
4 x 25	RM	7 x 2,20	1,2	1,8	27	1793
5 x 4	RE	1 x 2,2	1	1,8	18,3	640
5 x 16	RM	7 x 1,70	1	1,8	25,8	1472
5 x 50	SM	7 x 3,00	1,4	2,1	37	3498
5 x 70	SM	13 x 2,70	1,4	2,2	42,6	4956
5 x 95	SM	17 x 2,70	1,6	2,4	50	6748
5 x 120	SM	18 x 3,00	1,6	2,6	53,1	7941

NYBY-JZ, NYBY-OZ

number of cores x conductor cross-section	Construction	Construction of individual conductor	Insulation thickness	Sheath thickness	External diameter	Cable weight
N x mm2		N x mm	mm	mm	mm	Kg/km
Signalnini NYBY-JZ, NYBY-OZ
6 x 4	RE	1 x 2,2	1	1,8	21,4	800
7 x 4	RE	1 x 2,2	1	1,8	21,4	830
8 x 4	RE	1 x 2,2	1	1,8	22,6	930
10 x 4	RE	1 x 2,2	1	1,8	27,3	1125
12 x 4	RE	1 x 2,2	1	1,8	27	1190
14 x 4	RE	1 x 2,2	1	1,8	29,3	1390
16 x 4	RE	1 x 2,2	1	2	32	1850
19 x 4	RE	1 x 2,2	1	2	33,4	2055
6 x 6	RE	1 x 2,7	1	1,8	22,5	950
7 x 6	RE	1 x 2,7	1	1,8	22,5	1000
8 x 6	RE	1 x 2,7	1	1,8	24	1125
10 x 6	RE	1 x 2,7	1	1,9	29,1	1350
12 x 6	RE	1 x 2,7	1	1,9	29,8	1510
14 x 6	RE	1 x 2,7	1	1,9	32,5	2015
16 x 6	RE	1 x 2,7	1	2	33,7	2740
19 x 6	RE	1 x 2,7	1	2,1	35,5	2515

Power Cable

Power cables are used to transmit and distribute electrical energy. Power cables are commonly used in urban underground power grids, power station lead-out lines, power supply within industrial and mining enterprises, and over-the-river transmission lines.
