The control cable usually stands for PVC insulated and PVC sheathed control cable suitable for industrial and mining enterprises, energy and transportation departments, control and protection lines for AC rated voltages up to 450/750 volts.

Fire-resistant control cable product features and usage: This product has high fire-resistance performance. Under the direct combustion of flame, no short-circuit or short-circuit fault occurs within a certain period of time. Therefore, in the event of fire, it is beneficial to reduce losses and low smoke. Halogen cables are environmentally friendly cables, especially for electric power, large buildings, railways, ships and other industries that require high fire protection.

Use characteristics:

1. AC rated voltage: U0/U 0.6/1KV.

2, the highest long-term working temperature: flame retardant PVC insulation and sheath 70 ° C and 105 ° C; fluoroplastic insulation and sheath 200 ° C and 260 ° C; cross-linked polyethylene insulation 90 ° C; low-smoke halogen-free flame retardant polyolefin 70 ° C; low smoke zero halogen flame retardant crosslinked polyolefin 90 ° C and 120 ° C.

3, the minimum ambient temperature: flame retardant PVC sheath: fixed laying -40 ° C, non-fixed laying -15 ° C; fluoroplastic insulation and sheath: fixed laying -60 ° C; non-fixed laying -20 ° C.

4. The cable installation temperature is not lower than 0 °C.

5. Allowable bending radius recommended for laying: non-armored cable is not less than 6 times the outer diameter of the cable; armored cable is not less than 12 times the outer diameter of the cable; fluoroplastic insulated and sheathed cable is not less than 8 times the outer diameter of the cable

Commonly used models:

Flame retardant PVC insulated and sheathed fire control cable

Flame-retardant PVC insulated and sheathed copper wire braided shield fire-resistant control cable

Fluoroplastic insulated and sheathed fire control cable

Low-smoke low-halogen flame-retardant PVC insulated and sheathed fire-resistant control cable.

XLPE insulated flame-retardant PVC sheathed fire-resistant control cable.
