The product execution standard of rubber cable

Rubber cable production

product characteristics and application: This product is applicable to AC rated voltage 0.6/1kv and below fixed installation with power transmission line or mobile appliances with the connection cable, products with radiation heat resistance, cold resistance, acid alkali, and corrosive gas and waterproof properties, soft cable structure, convenient radiation, under the environment of high temperature (cold), stable electrical performance, anti-aging performance is outstanding, long service life, widely used in metallurgy, electric power, petrochemical, electronic, automobile manufacturing and other industries.

Q/HHTZH001.1

GB12666-90 requirements for the test of flame retardant properties

Three: the use of the characteristics of the product line:

1 AC rated voltage: 0.6/1KV U0/U

Maximum operating temperature: 180

Minimum ambient temperature: -60

2 cable installation temperature should be no less than -25.

3 cable allows bending radius: 10 times the diameter of the cable is the smallest.

Four: basic type and name

Rubber cable type

Product name

(ZR) -YGC

Silicone rubber sheathed power cable.

(ZR) -YEAR

Silicone rubber insulated and silicone rubber sheathed mobile power cable.

(ZR) -GCP

Silicon rubber insulated, silicone rubber sheathed copper braid shielded power cable.

(ZR) -YGC22

Silicon rubber insulated and sheathed power cable.

(ZR) -JGG

Silicone rubber insulated wire.

(ZR) -JGGR

With the installation of flexible silicon rubber insulation and sheath of mobile.

(ZR) -JGGP

Silicone rubber insulated and sheathed copper braid shielded wire.

(ZR) -JHXG

Silicone rubber insulation motor lead wire.
