Advantages and applications of flexible cables

The flexible cable according to the division of function mainly divided into sensor/encoder cable, servo motor cable, cable robot, cable clean, and drag chain cable.

The model can be divided into the following categories:

Flexible control cable

1. PVC outer sheath flexible control cable towline, flame retardant CC101 bending radius: 8X

2. PVC outer sheath flexible control cable shielding towline, flame retardant CC111 bending radius: 10X

3. PVC outer sheath flexible control cable towline, flame retardant CC120 bending radius: 5X

4. PVC outer sheath flexible control cable shielding towline, flame retardant CC121 bending radius: 8X

5. The PVC sheath flexible control cable towline, oil resistance, acid and alkali resistance, hydrolysis resistance, anti-ultraviolet, low-temperature resistance, wear resistance, flame retardant CC127 bending radius: 8x

6. And PVC sheath flexible control shielding towline cable, oil resistance, acid and alkali, hydrolysis resistant, anti-ultraviolet, low-temperature resistance, wear resistance, flame retardant CC117 bending radius: 10x

7. Steel wire braided flexible control cable towline, anti-ultraviolet radiation, low-temperature resistance, wear resistance, bending radius: 10X CC158

8. PETP outer sheath flexible control cable towline, oil resistance, acid and alkali resistance, hydrolysis resistance, anti-ultraviolet, low-temperature resistance, wear resistance, flame retardant CC160 bending radius: 5x

9. PETP outer sheath flexible control shielding towline cable, oil resistance, acid and alkali, hydrolysis resistant, anti-ultraviolet, low-temperature resistance, wear resistance, flame retardant CC133 bending radius: 10x

Flexible power cable

1. PVC outer sheath flexible power towline cable, flame retardant CC305 bending radius: 8X

2. PVC outer sheath shielded flexible power towline cable, flame retardant CC336 bending radius: 10X

3. PETP sheathed shielded flexible power cable towline, oil resistance, acid and alkali, hydrolysis resistant, anti-ultraviolet, low-temperature resistance, wear resistance, flame retardant CC358 bending radius: 10x

4. PETP sheathed shielded flexible power cable towline, oil resistance, acid and alkali resistance, hydrolysis resistance, anti-ultraviolet, low-temperature resistance, wear resistance, flame retardant CC371 bending radius: 8x

Flexible data/bus cable

1. PVC outer sheath flexible shielding towline cable data. CC41 bending radius: 8X

2. And PVC sheath flexible shielding data cable towline, oil resistance, acid and alkali, hydrolysis resistant, anti-ultraviolet, low-temperature resistance, wear resistance, flame retardant CC43 bending radius: 10x

3. PETP outer sheath flexible shielding data cable towline, oil resistance, acid and alkali, hydrolysis resistant, anti-ultraviolet, low-temperature resistance, wear resistance, flame retardant cc46 this bending radius: 10x

4. PETP outer sheath flexible shielding data cable towline, oil resistance, acid and alkali, hydrolysis resistant, anti-ultraviolet, low-temperature resistance, wear resistance, flame retardant CC48 bending radius: 12x

Flexible servo cable

PUR sheath flexible shielding servo towline cable, oil resistance, acid and alkali, hydrolysis resistant, anti-ultraviolet, low-temperature resistance, wear resistance, flame retardant cc46 this bending radius: 10x

Flexible cable is different from ordinary fixed installation cable, in the installation, please refer to the following installation and attention:

1. Towline cable laying is not distorted, that is, not to solve the cable from the cable drum and the cable reel at one end of the, but should first rotating drum or cable tray cable expansion, when necessary can be cable mounted or suspended. Cable for the occasion can only be obtained directly from the cable reel.

2. Must pay attention to the minimum bending radius of the cable. (information is available in the form of a selection).

3. The cable must be loose laying side by side in the drag chain, as far as possible arranged separately, with the separation of spacer separated or penetrated into the bracket neutral hole in drag chain cable between the gap should at least 10% of the diameter of the cable.

4. Towline of the cable must not touch each other or stuck together.

5. Two cables must be fixed, or at least, in the end, must be fixed chain motion. Mobile general cable towline from the end of the distance should be 20-30 times the cable diameter.

6. Please make sure that the cable is completely moved within the bending radius, so that is not to be forced to move. This cable with each other or with the guiding device by relative movement. After a period of operation, it is best to check the position of the cable. The check must be carried out after push and pull.

7. If the cable drag chain is broken, also needs to be replaced, because the damage caused by excessive tension can not be avoided.

The superiority of flexible cable.

Meet the requirements of the same electrical requirements, flexible cable than another similar cable diameter, lightweight. Flexible cable bending performance is very good, the minimum bending radius can reach 5 times the cable diameter.
