Application of rubber cables in engineering projects

Rubber cable is suitable for AC-rated voltage of 450 / 750V and the following household appliances, electric tools, mobile electrical equipment, electric welding machine, and a welding connecting line. Thin copper wire rubber YH rubber sheathed cable inner conductor cable, outsourcing rubber insulation rubber sheath soft, movable.

Rubber cables generally include general rubber sheathed soft cable, electric welder cable, electric welder cable, radio equipment, rubber sheathed cable, and photographic light source. Rubber sheathed cables are widely used in the electric, electrical, electrical, and other electrical equipment of the mobile power supply cord and can be used for indoor or outdoor environments.

According the rubber sheathed cable can bear external mechanical forces, the product structure can be divided into light, medium, and heavy three types, under normal circumstances: light rubber sheathed cables for home appliances, small electric equipment, soft, lightweight, good bending performance; medium-sized cab tire cable industry should be in addition to the use of agricultural electrification, heavy cable applications, for example, port machinery, searchlights, property of the large hydraulic pumping station occasions.

Waterproof rubber sheathed cable, submersible pump cable, mainly used for submersible motor matching, model JHS, JHSB cable radio device rubber sheathed cable. At present, our factory mainly produces two kinds of rubber sheathed cable tea set, whip the former is not shielded, after the shield.

Development of new light source, with the development of a new light source, with the advantages of a small structure, and good performance, can meet the needs of indoor and outdoor work. Rubber sheathed cable, rubber power cable heavy-duty rubber sheathed flexible cable (YC, YCW cable), medium rubber sheath soft cable (YZ, YZW cable), light rubber cover flexible cable (YQ, your cable, waterproof rubber cover flexible cable (JHS cable JHSB cable), electric welding machine rubber sheathed flexible cables, welding line (YH cable, YHF cable) the rubber sheath soft cable field tinned power line connection. Rubber cable electric welder rubber sheath soft cable YH, YHF welding line can be used in AC voltage not more than 200V and 400V peak pulse current electric welder secondary side wiring and connecting with the electrode holder.

It is suitable for electric welder secondary side wiring and connecting electric welding pliers special cable, AC rated voltage does not exceed 200V and 400V peak pulse current. For a single core structure, a multi-unit soft wire cutting machine. Using heat-resistant polyester film insulation tape as the core, using rubber insulation protection layer as a protective layer. Waterproof rubber sheath soft cable JHS JHS, just type waterproof rubber sheathed cable AC voltage 500V and below the submersible motor power transmission. In the long-term immersion and water pressure, with good electrical insulation properties.

The bending resistance of the waterproof rubber sheath is good, and it can be subjected to regular exercise. General rubber sheathed cable main performance: rated voltage U0 / 300 U / 500 (YZ, 450 750 (YC); the long-term working temperature of the core wire should be not more than 65 DEG C; "W" type cable is resistant to climate and oil resistance, suitable for use in outdoor and oil; electric welding machine cable rubber sheath secondary ac voltage not more than 200V, the current value is not more than 400V. General rubber sheathed flexible cable is generally divided into "light, medium, and heavy" types of product structures.
